Low Voltage Transformers, Energy Meters and Relay Panel Online Course

About This Course

In this Online Video Tutorial course, you will learn how Low Voltage Transformers work and get connected, including Transformer Calculations. Energy Meters and Relay Panels are also covered to assist you in Trade Test Preparation.

What You Will Learn

This course covers Low Voltage Transformers — how they work, how to connect them, and how to do the calculations. You will also learn about Energy Meter connections and Relay Panels.

Course Content (17 Lessons)

1. Working of a Transformer (10:07)
2. Step Down Transformer Calculations (11:54)
3. Step Up Transformer Calculations (08:22)
4. Transformer Power Factor (04:22)
5. Power Factor Calculations (07:32)
6. Transformer Star Delta Connections (13:06)
7. 3 Phase Transformer Calculations (23:18)
8. Connecting 3 Single Phase Transformers in Star Delta Configurations (15:07)
9. Transformer Tapping's Calculations (18:38)
10. PT Connected to a Voltmeter with a Selector Switch (11:30)
11. Ringing out a Voltmeter Selector Switch (08:37)
12. CT Connected to an Ammeter with a Selector Switch (09:37)
13. PT's and CT's in Trade Test (03:48)
14. Energy Meter Connections (09:19)
15. Energy Meters in Trade Test (13:45)
16. Relay Panel (19:10)
17. Fault Finding on Relay Panel (14:42)

Course Details

• 📚 Level: Intermediate
• ⏱ Duration: 3 hours 30 minutes
• 📋 17 Lessons
• 🎓 Certificate of Completion included
• 👨‍🏫 Instructors: Deon Jacobs & Romano Walters

Requirements

Please make sure you have a good understanding of the Basics of Electricity before pursuing this course.

Who Is This Course For?

If you are looking to prepare yourself better for a Trade Test or just want to upskill yourself in Low Voltage Transformers, Energy Meters and Relay Panels, then this course is perfect for you.
